Technical Overview
Dimensions (HxWxD)
223x834x527 mm
Cooktop type
Induction with integrated ventilation
Total number of positions that can be used at the same time
4
Type of frame
Flex Design: exchangeable side trims (select your favourite out of 4 colours)
Maximum output air extraction
500 m³/h
Sound power at max. speed (2010/30/EC)
69 dB
Home Connect Footnote 1: Some of the features displayed can be accessed only if the device is connected to a Home Connect Account and a SingleKey ID account via the Internet. Home Connect is a service of Home Connect GmbH. For more information on Home Connect, visit www.home-connect.com.
Yes
Key Features
Commitment To Excellence
Specifications
Main colour of product
Black
Type of appliance width
80 cm
Total number of positions that can be used at the same time
4
Dimensions of the heating elements (not applicable for gas)
4 x (20,0 x 23,0 cm)
Power of the heating elements (maximum values shown, depending on gas type)
4 x 2.2 (3.7) kW
Type of frame
Flex Design: exchangeable side trims (select your favourite out of 4 colours)
Number of radiant plates
0
Number of induction plates
4
heating with booster
All
Type of control setting and signalling devices
Rotary control
Maximum output air extraction
500 m³/h
Boost position air extraction
622 m³/h
Maximum output recirculating air
499 m³/h
Boost position output recirculating
595.0 m³/h
Sound power at max. speed (2010/30/EC)
69 dB
Sound power boost (2010/30/EC)
74 dB
Noise level
69 dB(A) re 1 pW
Energy consumption of hob
185.0 Wh/kg
Included accessories
1 x Slider for unducted recirculation, 1 x Clean Air Plus odor filter
Dimensions (HxWxD)
223x834x527 mm
Dimensions of the packed product (HxWxD)
430x940x660 mm
Minimum height for installation
490 mm
Maximum height for installation
500 mm
Minimum width for installation
750 mm
Maximum width for installation
750 mm
Depth for installation
223 mm
1 / 0
Connection Rating
7400 W
Voltage
220-240/380-415 V
Length electrical supply cord
110 cm
Plug type
No plug (electrical connection by licensed electrician)
User manuals included
[DE, EN]
Type of control
TwistPad Flex
hotplate control settings
17 power levels for each cooking zone
Cooking zone flexibility
2 flex induction cooking zones
powerBoost
Yes
Avoid scratches on glass ceramic with GlassProtect
No
activeLight Plus
No
PerfectFry
Yes
Infrared cooking sensor
No
Cooking Sensor
No
Powermove
No
Power Transfer
Yes
Quick Start
Yes
Keep warm function
No
Timer
Yes
Timer
Switch-off timer (on appliance), Count-down timer (can be chosen instead of switch-off timer)
SilentPowerDrive
Yes
Boost position
Yes
Delay Shut off modes
Yes
Clean filter reminders
Yes
Number of speed settings
17-stage + 2 intensive
Home ConnectFootnote 1: Some of the features displayed can be accessed only if the device is connected to a Home Connect Account and a SingleKey ID account via the Internet. Home Connect is a service of Home Connect GmbH. For more information on Home Connect, visit www.home-connect.com.
Yes
Home Connect Features
iService Remote, Remote monitoring
Safety device
Child lock, Safety shut-off, Pot detection, Overflow protection
