B57VS26N0B

B57VS26N0B


Built-in oven with VarioSteam and SLIDE&HIDE - fuller flavour and unrestricted access to the oven interior.

Technical Specifications

Heating Functions
  • Oven with 13 heating methods:
    CircoTherm
    CircoTherm® Eco
    Top/Bottom heating
    Top/bottom heating Eco
    Full surface grill
    Small area grill
    Pizza setting
    Bread Baking
    Bottom heating
    Slow cooking
    Defrost
    Keep warm
  • Additional heating methods with steam: Reheating, Dough Proving
  • Temperature range 40 °C - 275 °C
  • Cavity volume: 71 net usable litres
Design
  • Iilluminated ShiftControl
  • Anthracite enamel cavity with 4 shelf positions
Cleaning
  • Pyrolytic self cleaning
  • EasyClean Cleaning aid program
  • Full glass inner door - safer touch door
Convenience
  • 4.1" TFT colour and graphics display with ShiftControl
  • Temperature proposal
    Actual temperature display
    Optical temperature control
    Automatic Programming
    Sabbath setting
  • Additional functions:
    Descaling programme
    Steam cooking function (system steamer accessory required)
    Drying function
  • Slide&Hide door, SoftOpen
  • Supporting systems: Bake and Roast assist, Automatic Programs
  • Number of automatic programmes: 14 PC
  • Multipoint MeatProbe
  • Electronic clock
  • Rapid heating-up
  • LED light
  • Large 1 litre water tank
  • Water tank empty indicator
  • Location of the steam generator is outside of the cavity.
  • Cooling fan
  • Stainless-steel fan
  • Info button
  • Revolution handle
Hook-in racks / rails
  • Cavity with shelf support rails, Telescopic slide-out Accessory
Accessories
  • 2 x combination grid, 1 x universal pan
Safety and Environment
  • Individual adjustable child lock
    Residual heat indicator
    Safety switch off
  • Quadruple glass door panel
Technical Information
  • Length of mains cable: 120 cm
  • Total connected load electric: 3.45 KW
  • Appliance dimension (hxwxd): 595 mm x 596 mm x 548 mm
  • Installation dimensions (HxWxD): 585 mm - 595 mm x 560 mm - 568 mm x 550 mm
  • Please reference the built-in dimensions provided in the installation drawing
More Info
General
Width of the product (mm) 596 mm
Height of the product (mm) 595 mm
Usable volume (of cavity) - NEW (2010/30/EC) 71 l
Cooking method Bottom heat, Bread Baking Setting, Conventional heat, Defrost, Full width grill, Half width grill, Hot Air, Hot Air-Eco, Hot air grilling, low temperature cooking, Pizza setting, warming
TFT-Touchdisplay Plus
TFT-Touchdisplay
TFT-Display
Highlights activeClean, automatic programmes, Child-proof Lock, Fast Pre-heating function
Included accessories cavity 1 2 x combination grid, 1 x universal pan
Energy efficiency class (2010/30/EC) A+
Design
Color / Material Front Stainless steel
Construction type Built-in
Control Panel Material Stainless steel
Door Material Glass
Energy input Electric
Installation typology Built-in
Door hinge retractable
Size and weight
Cavity width (cm) 48.0 cm
Cavity height (cm) 35.7 cm
Cavity depth (cm) 41.5 cm
Dimensions of the product (mm) 595 x 596 x 548 mm
Cut-out width 560 mm
Cut-out height (mm) 585 mm
Cut-out depth 550 mm
Depth with door open (mm) 635 mm
Net weight (kg) 43.2 kg
Oven
Area of largest baking sheet 1,290
Hot air temperature max. (°C) 200 °C
T/b heating temperature max. (°C) 275 °C
Product size Large
Door temperature 30 °C
Consumption values
Max. e cons pyrol self-clean (kWh) 4.80 kWh
Min. e cons pyrol self-clean (kWh) 3.30 kWh
Energy efficiency class (2010/30/EC) A+
Energy consumption per cycle conventional (2010/30/EC) 0.87
Energy consumption per cycle forced air convection (2010/30/EC) 0.69
Comfort
Included accessories cavity 1 2 x combination grid, 1 x universal pan
Pull-out system Accessory
Are some hobs controls integrated?
Connection
Length electrical supply cord (cm) 120 cm
Current (A) 16 A
Electrical connection rating (W) 3,450 W
Plug type no plug
Voltage (V) 220-240 V
